<div class="table-container">
<div class="table-responsive">
Type 2.92mm, male (plug), straight, SP style connector for PT-092 type cables.
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Part Number&nbsp;</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">SP-PT092-KM</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Max Frequency (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">40</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Stock Code</td>
<td style="width: 24.2386%; height: 22px;">SP116</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">VSWR Freq</td>
<td style="width: 34.4153%; height: 22px;">1.09544511501033:1</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 19.4703%; height: 44px; background-color: #ecf0f1;">Interface</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 44px;">2.92mm</td>
<td style="width: 5.2944%; height: 44px;">&nbsp;</td>
<td style="width: 16.4328%; height: 44px; background-color: #ecf0f1;">VSWR Freq (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Gender</td>
<td style="width: 24.2386%; height: 22px;">male (plug)</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Coupling Nut</td>
<td style="width: 34.4153%; height: 22px;">y</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Orentation</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">Straight</td>
<td style="width: 5.2944%; height: 22px; border-style: none;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Inner Contact Attach</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: none;">
<td style="width: 19.4703%; height: 22px;">PIM Rating</td>
<td style="width: 24.2386%; height: 22px;">&nbsp;</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Outer Contact Attach</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: hidden; height: 22px;">
<td style="width: 19.4703%; background-color: #ecf0f1; border-style: none; height: 22px;">Impendance (ohms)</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">50</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; background-color: #ecf0f1; height: 22px;">Body Finish</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
</tbody>
</table>
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 27.4055%; height: 22px; background-color: #ecf0f1;">Pin Finish</td>
<td style="width: 14.4707%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
<tr style="height: 22px;">
<td style="width: 27.4055%; height: 22px;">Length (mm)</td>
<td style="width: 14.4707%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 27.4055%; height: 44px; background-color: #ecf0f1;">Length (in)</td>
<td style="width: 14.4707%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 27.4055%; height: 22px;">Width (mm)</td>
<td style="width: 14.4707%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 27.4055%; height: 22px; background-color: #ecf0f1;">Width (in)</td>
<td style="width: 14.4707%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 27.4055%; height: 22px;">Weight (g)</td>
<td style="width: 14.4707%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 27.4055%; background-color: #ecf0f1; height: 22px;">Weight (lb)</td>
<td style="width: 14.4707%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
</tbody>
</table>
&nbsp;
&nbsp;
</div>
<div class="table-responsive">&nbsp;</div>
</div>

Type 2.92mm, male (plug), straight, SP style connector for PT-092 type cables.

SP-PT092-KM

Type 2.92mm, male (plug), straight, SP style connector for PT-092 type cables.


<div class="table-container">
<div class="table-responsive">
Type 2.92mm, male (plug), straight, SP style connector for PT-092 type cables.
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Part Number&nbsp;</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">SP-IBP092-KM-RA</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Max Frequency (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">40</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Stock Code</td>
<td style="width: 24.2386%; height: 22px;">SP057</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">VSWR Freq</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 19.4703%; height: 44px; background-color: #ecf0f1;">Interface</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 44px;">2.92mm</td>
<td style="width: 5.2944%; height: 44px;">&nbsp;</td>
<td style="width: 16.4328%; height: 44px; background-color: #ecf0f1;">VSWR Freq (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Gender</td>
<td style="width: 24.2386%; height: 22px;">male (plug)</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Coupling Nut</td>
<td style="width: 34.4153%; height: 22px;">y</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Orentation</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">Right Angle</td>
<td style="width: 5.2944%; height: 22px; border-style: none;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Inner Contact Attach</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: none;">
<td style="width: 19.4703%; height: 22px;">PIM Rating</td>
<td style="width: 24.2386%; height: 22px;">&nbsp;</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Outer Contact Attach</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: hidden; height: 22px;">
<td style="width: 19.4703%; background-color: #ecf0f1; border-style: none; height: 22px;">Impendance (ohms)</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">50</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; background-color: #ecf0f1; height: 22px;">Body Finish</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">Passivate, AMS-2700</td>
</tr>
</tbody>
</table>
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 27.5437%; height: 22px; background-color: #ecf0f1;">Pin Finish</td>
<td style="width: 14.3325%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
<tr style="height: 22px;">
<td style="width: 27.5437%; height: 22px;">Length (mm)</td>
<td style="width: 14.3325%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 27.5437%; height: 44px; background-color: #ecf0f1;">Length (in)</td>
<td style="width: 14.3325%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 27.5437%; height: 22px;">Width (mm)</td>
<td style="width: 14.3325%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 27.5437%; height: 22px; background-color: #ecf0f1;">Width (in)</td>
<td style="width: 14.3325%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 27.5437%; height: 22px;">Weight (g)</td>
<td style="width: 14.3325%; height: 22px;">&nbsp;4.7</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 27.5437%; background-color: #ecf0f1; height: 22px;">Weight (lb)</td>
<td style="width: 14.3325%; background-color: #ecf0f1; height: 22px;">&nbsp;0.010361726</td>
</tr>
</tbody>
</table>
&nbsp;
&nbsp;
</div>
<div class="table-responsive">&nbsp;</div>
</div>

Type 2.92mm, male (plug), right angle, SP style connector for PT092 type cables.

SP-IBP092-KM-RA

Type 2.92mm, male (plug), right angle, SP style connector for PT092 type cables.


<div class="table-container">
<div class="table-responsive">
Type SMA, male (plug), right angle, SP style connector for SPFLT140 type cables.
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Part Number&nbsp;</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">SP-SPFLT140-SM-RA</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Max Frequency (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">22</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Stock Code</td>
<td style="width: 24.2386%; height: 22px;">SP047</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">VSWR Freq</td>
<td style="width: 34.4153%; height: 22px;">1.30:1</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 19.4703%; height: 44px; background-color: #ecf0f1;">Interface</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 44px;">SMA</td>
<td style="width: 5.2944%; height: 44px;">&nbsp;</td>
<td style="width: 16.4328%; height: 44px; background-color: #ecf0f1;">VSWR Freq (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Gender</td>
<td style="width: 24.2386%; height: 22px;">male (plug)</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Coupling Nut</td>
<td style="width: 34.4153%; height: 22px;">y</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Orentation</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">Right Angle</td>
<td style="width: 5.2944%; height: 22px; border-style: none;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Inner Contact Attach</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: none;">
<td style="width: 19.4703%; height: 22px;">PIM Rating</td>
<td style="width: 24.2386%; height: 22px;">&nbsp;</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Outer Contact Attach</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: hidden; height: 22px;">
<td style="width: 19.4703%; background-color: #ecf0f1; border-style: none; height: 22px;">Impendance (ohms)</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">50</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; background-color: #ecf0f1; height: 22px;">Body Finish</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
</tbody>
</table>
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Pin Finish</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Length (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 28.0958%; height: 44px; background-color: #ecf0f1;">Length (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Width (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Width (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Weight (g)</td>
<td style="width: 13.7804%; height: 22px;">10</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; background-color: #ecf0f1; height: 22px;">Weight (lb)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">&nbsp;0.022046226</td>
</tr>
</tbody>
</table>
&nbsp;
&nbsp;
</div>
<div class="table-responsive">&nbsp;</div>
</div>

Type SMA, male (plug), right angle, SP style connector for SPFLT140 type cables.

SP-SPFLT140-SM-RA

Type SMA, male (plug), right angle, SP style connector for SPFLT140 type cables.


<div class="table-container">
<div class="table-responsive">
Type 3.5mm, male (plug), straight, SP style connector for SPFLT200 type cables.
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Part Number&nbsp;</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">SP-SPFLT200-35M</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Max Frequency (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Stock Code</td>
<td style="width: 24.2386%; height: 22px;">SP023</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">VSWR Freq</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 19.4703%; height: 44px; background-color: #ecf0f1;">Interface</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 44px;">3.5mm</td>
<td style="width: 5.2944%; height: 44px;">&nbsp;</td>
<td style="width: 16.4328%; height: 44px; background-color: #ecf0f1;">VSWR Freq (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Gender</td>
<td style="width: 24.2386%; height: 22px;">male (plug)</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Coupling Nut</td>
<td style="width: 34.4153%; height: 22px;">y</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Orentation</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">Straight</td>
<td style="width: 5.2944%; height: 22px; border-style: none;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Inner Contact Attach</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: none;">
<td style="width: 19.4703%; height: 22px;">PIM Rating</td>
<td style="width: 24.2386%; height: 22px;">&nbsp;</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Outer Contact Attach</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: hidden; height: 22px;">
<td style="width: 19.4703%; background-color: #ecf0f1; border-style: none; height: 22px;">Impendance (ohms)</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">50</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; background-color: #ecf0f1; height: 22px;">Body Finish</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
</tbody>
</table>
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Pin Finish</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Length (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 28.0958%; height: 44px; background-color: #ecf0f1;">Length (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Width (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Width (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Weight (g)</td>
<td style="width: 13.7804%; height: 22px;">8.1</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; background-color: #ecf0f1; height: 22px;">Weight (lb)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">0.017857443</td>
</tr>
</tbody>
</table>
&nbsp;
&nbsp;
</div>
<div class="table-responsive">&nbsp;</div>
</div>

Type 3.5mm, male (plug), straight, SP style connector for SPFLT200 type cables.

SP-SPFLT200-35M

Type 3.5mm, male (plug), straight, SP style connector for SPFLT200 type cables.

<div class="table-container">
<div class="table-responsive">
Type SMA, female (jack), straight, SP style connector for PT140 type cables.
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Part Number&nbsp;</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">SP-PF140-SF-BH</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Max Frequency (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">22</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Stock Code</td>
<td style="width: 24.2386%; height: 22px;">SP042</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">VSWR Freq</td>
<td style="width: 34.4153%; height: 22px;">1.30:1</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 19.4703%; height: 44px; background-color: #ecf0f1;">Interface</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 44px;">SMA</td>
<td style="width: 5.2944%; height: 44px;">&nbsp;</td>
<td style="width: 16.4328%; height: 44px; background-color: #ecf0f1;">VSWR Freq (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Gender</td>
<td style="width: 24.2386%; height: 22px;">female (jack)</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Coupling Nut</td>
<td style="width: 34.4153%; height: 22px;">y</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Orentation</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">Straight</td>
<td style="width: 5.2944%; height: 22px; border-style: none;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Inner Contact Attach</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: none;">
<td style="width: 19.4703%; height: 22px;">PIM Rating</td>
<td style="width: 24.2386%; height: 22px;">&nbsp;</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Outer Contact Attach</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: hidden; height: 22px;">
<td style="width: 19.4703%; background-color: #ecf0f1; border-style: none; height: 22px;">Impendance (ohms)</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">50</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; background-color: #ecf0f1; height: 22px;">Body Finish</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">Passivate, AMS-2700</td>
</tr>
</tbody>
</table>
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Pin Finish</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Length (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 28.0958%; height: 44px; background-color: #ecf0f1;">Length (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Width (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Width (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Weight (g)</td>
<td style="width: 13.7804%; height: 22px;">10.5</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; background-color: #ecf0f1; height: 22px;">Weight (lb)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">&nbsp;0.023148538</td>
</tr>
</tbody>
</table>
&nbsp;
&nbsp;
</div>
<div class="table-responsive">&nbsp;</div>
</div>

Type SMA, female (jack), straight, SP style connector for PT140 type cables.

SP-PF140-SF-BH

Type SMA, female (jack), straight, SP style connector for PT140 type cables.


<div class="table-container">
<div class="table-responsive">
Type ATNC, male (plug), straight, SP style connector for PT210 type cables.
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Part Number&nbsp;</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">SP-PF210-ATM</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Max Frequency (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Stock Code</td>
<td style="width: 24.2386%; height: 22px;">SP001</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">VSWR Freq</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 19.4703%; height: 44px; background-color: #ecf0f1;">Interface</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 44px;">ATNC</td>
<td style="width: 5.2944%; height: 44px;">&nbsp;</td>
<td style="width: 16.4328%; height: 44px; background-color: #ecf0f1;">VSWR Freq (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Gender</td>
<td style="width: 24.2386%; height: 22px;">male (plug)</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Coupling Nut</td>
<td style="width: 34.4153%; height: 22px;">y</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Orentation</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">Straight</td>
<td style="width: 5.2944%; height: 22px; border-style: none;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Inner Contact Attach</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: none;">
<td style="width: 19.4703%; height: 22px;">PIM Rating</td>
<td style="width: 24.2386%; height: 22px;">&nbsp;</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Outer Contact Attach</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: hidden; height: 22px;">
<td style="width: 19.4703%; background-color: #ecf0f1; border-style: none; height: 22px;">Impendance (ohms)</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">50</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; background-color: #ecf0f1; height: 22px;">Body Finish</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
</tbody>
</table>
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Pin Finish</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Length (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 28.0958%; height: 44px; background-color: #ecf0f1;">Length (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Width (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Width (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Weight (g)</td>
<td style="width: 13.7804%; height: 22px;">19.5</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; background-color: #ecf0f1; height: 22px;">Weight (lb)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">&nbsp;0.042990141</td>
</tr>
</tbody>
</table>
&nbsp;
&nbsp;
</div>
<div class="table-responsive">&nbsp;</div>
</div>

Type ATNC, male (plug), straight, SP style connector for PT210 type cables.

SP-PF210-ATM

Type ATNC, male (plug), straight, SP style connector for PT210 type cables.


<div class="table-container">
<div class="table-responsive">
Type SMA, male (plug), straight, SP style connector for PT140/PT150 type cables.
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Part Number&nbsp;</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">SP-PT140-150-SM</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Max Frequency (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Stock Code</td>
<td style="width: 24.2386%; height: 22px;">SP002</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">VSWR Freq</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 19.4703%; height: 44px; background-color: #ecf0f1;">Interface</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 44px;">SMA</td>
<td style="width: 5.2944%; height: 44px;">&nbsp;</td>
<td style="width: 16.4328%; height: 44px; background-color: #ecf0f1;">VSWR Freq (GHz)</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 19.4703%; height: 22px;">Gender</td>
<td style="width: 24.2386%; height: 22px;">male (plug)</td>
<td style="width: 5.2944%; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Coupling Nut</td>
<td style="width: 34.4153%; height: 22px;">y</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 19.4703%; height: 22px; background-color: #ecf0f1;">Orentation</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">Straight</td>
<td style="width: 5.2944%; height: 22px; border-style: none;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px; background-color: #ecf0f1;">Inner Contact Attach</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: none;">
<td style="width: 19.4703%; height: 22px;">PIM Rating</td>
<td style="width: 24.2386%; height: 22px;">&nbsp;</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; height: 22px;">Outer Contact Attach</td>
<td style="width: 34.4153%; height: 22px;">&nbsp;</td>
</tr>
<tr style="border-style: hidden; height: 22px;">
<td style="width: 19.4703%; background-color: #ecf0f1; border-style: none; height: 22px;">Impendance (ohms)</td>
<td style="width: 24.2386%; background-color: #ecf0f1; height: 22px;">50</td>
<td style="width: 5.2944%; border-style: none; height: 22px;">&nbsp;</td>
<td style="width: 16.4328%; background-color: #ecf0f1; height: 22px;">Body Finish</td>
<td style="width: 34.4153%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
</tbody>
</table>
&nbsp;
<table style="border-collapse: collapse; width: 95.9601%; height: 176px; border-style: hidden;">
<tbody>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Pin Finish</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">Gold Plate, MIL-DTL-45204</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Length (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 44px; border-style: hidden;">
<td style="width: 28.0958%; height: 44px; background-color: #ecf0f1;">Length (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 44px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Width (mm)</td>
<td style="width: 13.7804%; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; height: 22px; background-color: #ecf0f1;">Width (in)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">&nbsp;</td>
</tr>
<tr style="height: 22px;">
<td style="width: 28.0958%; height: 22px;">Weight (g)</td>
<td style="width: 13.7804%; height: 22px;">4.2</td>
</tr>
<tr style="height: 22px; border-style: hidden;">
<td style="width: 28.0958%; background-color: #ecf0f1; height: 22px;">Weight (lb)</td>
<td style="width: 13.7804%; background-color: #ecf0f1; height: 22px;">&nbsp;0.009259415</td>
</tr>
</tbody>
</table>
&nbsp;
&nbsp;
</div>
<div class="table-responsive">&nbsp;</div>
</div>

Type SMA, male (plug), straight, SP style connector for PT140/PT150 type cables.

SP-PT140-150-SM

Type SMA, male (plug), straight, SP style connector for PT140/PT150 type cables.

The SpaceFlight product line embodies the critical requirements necessary for reliable performance in space. Cable assemblies must utilize low outgassing materials in a vacuum environment along with non‐polymeric. Our proprietary material conditioning and vacuum testing of assemblies ensure outgassing is minimized in space flight and thermal vacuum-rated test cable assemblies. In addition, these coaxial cable assemblies meet the NASA standards outlined in ASTM E‐595 for outgassing characteristics, so trust our teams to provide the expertise necessary to give you the leading-edge performance you need for challenging space applications.

SpaceFlight

PhaseTrack&nbsp;cable assemblies are designed for applications demanding minimal phase change over temperature. All PhaseTrack cables use a proprietary TF4&trade; dielectric that does not have the abrupt shift in the phase that occurs with solid- or tape-wrapped PTFE-based products under normal room ambient temperature conditions.

PhaseTrack Assemblies

Microwave connectors are small connectors designed for high frequency environments up to 60 GHz.

Microwave Connectors
