PT-210-SP

The PhaseTrack^®210 is an Ultra-Flexible phase-stable coax assembly featuring a proprietary fluorocarbon dielectric, TF4^®, eliminating the PTFE change phase occurring around 19 ºC. PhaseTrack assemblies have the same triple-shield construction used in our popular SF^®, SFT^®, SilverLine^®, and MilTtech^® cables and are ideal for applications demanding stable phase over temperature.



Part Number	PT-120-SP		Bending Moment (Nm)
Environment			Bending Moment (ft-lb)
Jacket	ETFE		Max Frequency (GHz)-	-
Overall Diameter (mm)	5.715		Impedance (ohms)	50
Overall Diameter (in)	0.225		Power Handling (DWV)	-



Weight Kg/m	0.0823
Weight lb/ft	0.0553
Operating Temp.°C (°F)	-150° to 150°C (-238° to 302°F
Min. Bend Radius (mm)	-
Min. Bend Radius (in)	1.125
